tTanic®T135P Positive

Lattonedil’s roofing sheets are the ideal solution for logistics-related constructions. This system is particularly suitable for large buildings and consists of a tTanic profiled sheet overlaid on the structural beams, an ISO TT insulation layer by Lattonedil, and a roofing package made of walkable membrane or polyolefins that can also be equipped with photovoltaic modules using the Eurosolar Zero system by Lattonedil.
This system offers numerous advantages, including minimized structural encumbrance, maximum usability in the layout, and reduced weight of the structure. This leads to significant benefits even in terms of foundations.

MATERIAL
Steel S 320 GD + Z200 o 275 wg
Steel S 320 GD + AZ150 o 185 wg

FINISHES
Glossy polyester gr. 25 µm
Matt polyester gr. 35 µm
Polyurethane gr. 50 µm
HPS200® gr. 200 µm

Profile height: 135 mm
Effective width: 930 / 620 mm
Total width: 980 / 650 mm
Sheet thickness: 0,75 mm, 0,88 mm, 1,00 mm, 1,25 mm, 1,50 mm
