tTanic®T130 Negative

The tTanic roofing sheet by Lattonedil is the ideal solution for buildings dedicated to the logistics sector. This system is particularly suitable for large-scale structures and consists of a layer of tTanic trapezoidal corrugated steel sheet laid over the structural beams, an ISO TT insulation layer by Lattonedil, and a roofing system made of membrane or polyolefins. The roof is fully walkable and can also be equipped with photovoltaic modules using the Lattonedil Eurosolar Zero system.

It also offers numerous advantages, including minimized structural bulk, maximum usable floor space, and reduced structural weight. These features result in significant benefits, particularly in terms of foundation design.

MATERIAL
Steel S 320 GD + Z200 o 275 wg
Steel S 320 GD + AZ150 o 185 wg

FINISHES
Glossy polyester gr. 25 µm
Matt polyester gr. 35 µm
Polyurethane gr. 50 µm
HPS200® gr. 200 µm

Profile height: 130 mm
Effective width: 1011 / 674 mm
Total width: 1046 / 698 mm
Sheet thickness: 0,75 mm, 0,88 mm, 1,00 mm, 1,25 mm, 1,50 mm
