tTanic ® T150 Negativa

Lattonedil’s roofing sheets are the ideal solution for logistics-related constructions. This system is particularly suitable for large buildings and consists of a tTanic profiled sheet overlaid on the structural beams, an ISO TT insulation layer by Lattonedil, and a roofing package made of walkable membrane or polyolefins that can also be equipped with photovoltaic modules using the Eurosolar Zero system by Lattonedil.
This system offers numerous advantages, including minimized structural encumbrance, maximum usability in the layout, and reduced weight of the structure. This leads to significant benefits even in terms of foundations.

MATERIALE / MATERIAL
Acciaio / Steel S 320 GD + Z200 o 275 wg
Acciaio / Steel S 320 GD + AZ150 o 185 wg

FINITURE / FINISHES
Poliestere lucido / Glossy polyester gr. 25 µm
Poliestere opaco / Matt polyester gr. 35 µm
Poliuretano / Polyurethane gr. 50 µm
HPS200® gr. 200 µm

Altezza del profilo / Profile height: 150 mm
Larghezza utile / Effective width: 870 / 580 mm
Larghezza totale / Total width: 902 / 598 mm
Spessore della lamiera / Sheet thickness:
0,75 mm, 0,88 mm, 1,00 mm, 1,25 mm, 1,50 mm
