Have we ever told you about Lattonedil sectional panels?
We Are
Visionaries
We know that we are not the only manufacturer of sectional panels, and that is precisely why we try to be!
Research & Technology
Exclusive spatulated plaster finish
1
Immediate availability
1
MAIN FEATURES OF ISOPEN LATTONEDIL PANELS
Thermal and acoustic insulation Thanks to the insulating core, they offer excellent thermal and acoustic properties, reducing heat and noise loss.
Robustness and durability
The metal materials used for the outer layers are impact, weather and corrosion resistant, ensuring a long service life.
Ease of installation
They adapt to the fastening and sliding system you produce Security
Many of these panels include safety systems to prevent accidents when opening and closing the door.
Customisable design
They can be produced in various colours and degrees of design and finish to match the aesthetics of the buildings in which they are installed.
2
Cut to size resulting in a reduction of your stock
2
APPLICATIONS
Residential
Garage doors for homes, which can be operated manually or with electric motors.
Industrial
Large gates for warehouses, warehouses and other industrial buildings, often with considerable dimensions and technical specifications for intensive use.
3
Maximum aesthetic performance
3
ADVANTAGES
Energy efficiency
Thanks to their thermal insulation, they help maintain constant temperatures inside buildings, reducing energy costs.
Low maintenance
Strong and durable materials require little maintenance over time.
Versatility
Suitable for a wide range of applications, they can be customised according to specific project requirements.
A complete range
Residential & Professional
isOpen® Flat Materia
Insulation panels for residential sectional doors
| Metal sheet | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 |
| External side | Without mouldings |
| External finishing | Smooth |
| External finishing Options | Stucco, Woodgrain, Materia (spatulated plaster finish) |
| Internal side | Stucco Ribbed |
isOpen® Flat
Insulation panels for residential sectional doors
| Metal sheet | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 |
| External side | Without mouldings |
| External finishing | Smooth |
| External finishing Options | Stucco, Woodgrain, Materia (spatulated plaster finish) |
| Internal side | Stucco Ribbed |
isOpen® Doga
Insulation panels for residential sectional doors
| Metal sheet | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 |
| External side | Middle Groove |
| External finishing | Smooth |
| External finishing Options | Smooth, Woodgrain |
| Internal side | Stucco Ribbed |
isOpen® Stripes
Insulation panels for residential sectional doors
| Metal sheet | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 |
| External side | Ribbed |
| External finishing | Stucco |
| External finishing Options | Smooth, Woodgrain |
| Internal side | Stucco Ribbed |
isOpen® Diamond
Insulation panels for residential sectional doors
| Metal sheet | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 |
| External side | Microribbed |
| External finishing | Smooth |
| Internal sideStucco Ribbed |
isOpen® PRO Flat
Insulation panels for professional sectional doors
| Metal sheet | Steel EN10346 | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm | 80 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) | 5,50 (500 mm) / 6,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 | Min. 2000 – Max. 13500 |
| External side | Without mouldings | Without mouldings |
| External finishing | Stucco | Stucco |
| External finishing Options | Smooth, Woodgrain | Smooth, Woodgrain |
| Internal Side | Stucco Ribbed | Stucco Ribbed |
isOpen® PRO Stripes
Insulation panels for professional sectional doors
| Metal sheet | Steel EN10346 | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm | 80 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) | 5,50 (500 mm) / 6,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 | Min. 2000 – Max. 13500 |
| External side | Ribbed | Ribbed |
| External finishing | Stucco | Stucco |
| External finishing Options | Smooth, Woodgrain | Smooth, Woodgrain |
| Internal Side | Stucco Ribbed | Stucco Ribbed |
isOpen® PRO Diamond
Insulation panels for professional sectional doors
| Metal sheet | Steel EN10346 | Steel EN10346 |
| Insulating | Isolant PUR (CFC & HCFC Free) | Isolant PUR (CFC & HCFC Free) |
| Thickness | 40 mm | 80 mm |
| Weight | 4,80 (500 mm) / 5,50 (610 mm) | 5,50 (500 mm) / 6,50 (610 mm) |
| Length | Min. 2000 – Max. 13500 | Min. 2000 – Max. 13500 |
| External side | Microribbed | Microribbed |
| External finishing | Smooth | Smooth |
| Internal Side | Stucco Ribbed | Stucco Ribbed |
Finishing
Design possibilities
RAL colors
Wood finishes
Plaster colors
Interior colors
